The TL-SF1008D Fast Ethernet Switch is designed for SOHO (Small Office/Home Office) or work group users. All 8 ports support auto MDI/MDIX, no need to worry about the cable type, simply plug and play.
TL-SF1008D Fast Ethernet Switch provides 8 10/100Mbps Auto-Negotiation RJ45 ports. All ports support Auto MDI/MDIX function, eliminating the need for crossover cables or Uplink ports. Featuring non-blocking switching architecture, TL-SF1008D forwards and filters packets at full wire-speed for maximum throughput.And IEEE 802.3x flow control for Full Duplex mode and back pressure for Half Duplex mode alleviate the traffic congestion and make TL-SF1008D work reliably.
The auto features of this switch make installation plug and play and hassle-free. No configuring is required. Auto MDI/MDIX eliminates the need for crossover cables. Auto-negotiation on each port senses the link speed of a network device (10, 100 Mbps) and intelligently adjusts for compatibility and optimal performance.
HARDWARE FEATURES
Standards and Protocols IEEE 802.3, IEEE 802.3u, IEEE 802.3x
CSMA/CD
Interface 8 10/100Mbps Ports, Auto-Negotiation, Auto-MDI/MDIX
Fan Quantity Fanless
External Power Supply 100-240VAC, 50/60Hz
(Output: 9VDC / 0.6A)
Buffer Size 768Kb
Data Rates 10/100Mbps at Half Duplex ;
20/200Mbps at Full Duplex
LED Indicator Power
Port network activity (on the network module)
Dimensions ( W x D x H ) 5.3 × 3.1 × 0.9 in.
(135 × 79 × 23mm)
Max Power Consumption 2W
Max Heat Dissipation 7.0 BTU/h
SOFTWARE FEATURES
Transfer Method Store and Forward
Advanced Functions Green Technology
802.3X Flow Control, Back Pressure
OTHERS
Certification FCC, RoHS
Package Contents 8-Port 10/100Mbps Desktop Switch
Power Adapter
User Guide
Environment Operating Temperature: 0°C~40°C
Storage Temperature: -40℃~60℃
Storage Humidity: 5%~90% non-condensing
